Schweitzer Luiz, Cunha Alexandre, Pereira Thiago, Mika Kerstin, Botelho do Rego Ana Maria, Ferraria Ana Maria, Kieburg Heinz, Geissler Sven, Uhlmann Eckart, Schoon Janosch
Fraunhofer Institute for Production Systems and Design Technology, Pascalstr. 8-9, 10587 Berlin, Germany.
Department of Orthopedics and Orthopedic Surgery, University Medicine Greifswald, 17475 Greifswald, Germany.
Materials (Basel). 2020 Nov 25;13(23):5342. doi: 10.3390/ma13235342.
Loosening of orthodontic and orthopedic implants is a critical and common clinical problem. To minimize the numbers of revision surgeries due to peri-implant inflammation or insufficient osseointegration, developments of new implant manufacturing strategies are indicated. Ultrafast laser surface texturing is a promising contact-free technology to modify the physicochemical properties of surfaces toward an anti-infectious functionalization. This work aims to texture Ti6Al4V surfaces with ultraviolet (UV) and green (GR) radiation for the manufacturing of laser-induced periodic surface structures (LIPSS). The assessment of these surface modifications addresses key aspects of topography, morphology and chemical composition. Human primary mesenchymal stromal cells (hMSCs) were cultured on laser-textured and polished Ti6Al4V to characterize the surfaces in terms of their in vitro biocompatibility, cytotoxicity, and metal release. The outcomes of the in vitro experiment show the successful culture of hMSCs on textured Ti6Al4V surfaces developed within this work. Cells cultured on LIPSS surfaces were not compromised in terms of their viability if compared to polished surfaces. Yet, the hMSC culture on UV-LIPSS show significantly lower lactate dehydrogenase and titanium release into the supernatant compared to polished. Thus, the presented surface modification can be a promising approach for future applications in orthodontics and orthopedics.
正畸和矫形植入物的松动是一个关键且常见的临床问题。为了尽量减少因种植体周围炎症或骨整合不足而进行翻修手术的次数,需要开发新的植入物制造策略。超快激光表面纹理化是一种很有前景的非接触技术,可改变表面的物理化学性质以实现抗感染功能化。这项工作旨在用紫外线(UV)和绿光(GR)辐射对Ti6Al4V表面进行纹理化处理,以制造激光诱导周期性表面结构(LIPSS)。对这些表面改性的评估涉及形貌、形态和化学成分等关键方面。将人原代间充质基质细胞(hMSCs)培养在经过激光纹理化处理和抛光的Ti6Al4V上,以从体外生物相容性、细胞毒性和金属释放方面对表面进行表征。体外实验结果表明,hMSCs成功培养在本研究中制备的纹理化Ti6Al4V表面上。与抛光表面相比,在LIPSS表面上培养的细胞活力没有受到影响。然而,与抛光表面相比,在UV-LIPSS上培养的hMSCs的乳酸脱氢酶和钛释放到上清液中的量显著更低。因此,所提出的表面改性对于正畸和矫形的未来应用可能是一种有前景的方法。
