Zhao Xiao, Lu Hengxiao, Zhang Zhenjiang
Department of Thoracic Surgery, Weifang People's Hospital, Weifang 261000, China.
Zhongguo Fei Ai Za Zhi. 2021 Oct 20;24(10):683-689. doi: 10.3779/j.issn.1009-3419.2021.101.39.
Computed tomography (CT) three-dimensional reconstruction technology is increasingly used in preoperative planning of patients with ground glass nodule (GGN), but how to accurately locate the nodule and ensure the safe resection edge is still a difficult problem for clinicians. The purpose of this study was to investigate the accuracy, convenience and safety of CT three-dimensional reconstruction combined with intraoperative natural collapse localization in total thoracoscopic segmental pneumonectomy.
A total of 45 patients with radiographic findings of pulmonary GGN admitted from July 2019 to December 2019 were selected as the study group. All patients received thin-slice CT scan and underwent preoperative three-dimensional reconstruction. After anesthesia, the small thoracic operation opening and the airway of the patients were quickly opened, and the lung was rapidly and naturally collapsed by pressure difference. GGN were positioned according to the natural marker line, and marked with 3-0 prolene line. After specimen removal, the distance between the GGN and the suture mark, the distance between the GGN and the incision margin were measured, and the incision margin was routinely examined. The general clinical data, pathological data and postoperative complications were counted and compared with 45 consecutive patients who were located with hookwire positioning needle in the same period.
The average localization time of non-invasive GGN with natural lung collapse during operation was 6.9 min, and the localization accuracy was 90.6%. There were 2 cases of extensive pleural adhesion and 1 case of emphysema. Postoperative pathology was confirmed as lung adenocarcinoma, and the examination of incision margin was negative. No GGNs were scanned again after surgery, and the precise resection rate of lung segment was 100.0%.
CT three-dimensional reconstruction combined with GGN localization of natural lung collapse during operation can shorten the time of searching for GGN during operation and guarantee the safety of the incision margin. It is a more economical and convenient localization method and makes pulmonary segment resection more accurate.
计算机断层扫描(CT)三维重建技术在磨玻璃结节(GGN)患者的术前规划中应用越来越广泛,但如何准确地定位结节并确保安全切缘仍是临床医生面临的难题。本研究旨在探讨CT三维重建联合术中肺自然萎陷定位在全胸腔镜肺段切除术中的准确性、便利性及安全性。
选取2019年7月至2019年12月收治的45例影像学检查发现肺部GGN的患者作为研究组。所有患者均接受薄层CT扫描并进行术前三维重建。麻醉后,迅速打开患者的小切口开胸及气道,利用压差使肺快速自然萎陷。根据自然标记线定位GGN,并用3-0普理灵缝线标记。标本切除后,测量GGN与缝线标记的距离、GGN与切口边缘的距离,并常规检查切缘。统计一般临床资料、病理资料及术后并发症,并与同期45例采用钩丝定位针定位的连续患者进行比较。
术中肺自然萎陷定位非侵袭性GGN的平均定位时间为6.9分钟,定位准确率为90.6%。有2例广泛胸膜粘连和1例肺气肿。术后病理确诊为肺腺癌,切缘检查为阴性。术后未再次扫描到GGN,肺段精确切除率为100.0%。
CT三维重建联合术中GGN肺自然萎陷定位可缩短术中寻找GGN的时间,保证切缘安全。是一种更经济、方便的定位方法,使肺段切除更精确。
