Department of Radiology, Massachusetts General Hospital (MGH), Harvard Medical School, 55 Fruit Street, Boston, MA, 02114, USA.
Athinoula A. Martinos Center for Biomedical Imaging, Charlestown, MA, USA.
Eur Radiol. 2023 Apr;33(4):2905-2915. doi: 10.1007/s00330-022-09265-6. Epub 2022 Dec 2.
High-resolution post-contrast T1-weighted imaging is a workhorse sequence in the evaluation of neurological disorders. The T1-MPRAGE sequence has been widely adopted for the visualization of enhancing pathology in the brain. However, this three-dimensional (3D) acquisition is lengthy and prone to motion artifact, which often compromises diagnostic quality. The goal of this study was to compare a highly accelerated wave-controlled aliasing in parallel imaging (CAIPI) post-contrast 3D T1-MPRAGE sequence (Wave-T1-MPRAGE) with the standard 3D T1-MPRAGE sequence for visualizing enhancing lesions in brain imaging at 3 T.
This study included 80 patients undergoing contrast-enhanced brain MRI. The participants were scanned with a standard post-contrast T1-MPRAGE sequence (acceleration factor [R] = 2 using GRAPPA parallel imaging technique, acquisition time [TA] = 5 min 18 s) and a prototype post-contrast Wave-T1-MPRAGE sequence (R = 4, TA = 2 min 32 s). Two neuroradiologists performed a head-to-head evaluation of both sequences and rated the visualization of enhancement, sharpness, noise, motion artifacts, and overall diagnostic quality. A 15% noninferiority margin was used to test whether post-contrast Wave-T1-MPRAGE was noninferior to standard T1-MPRAGE. Inter-rater and intra-rater agreement were calculated. Quantitative assessment of CNR/SNR was performed.
Wave-T1-MPRAGE was noninferior to standard T1-MPRAGE for delineating enhancing lesions with unanimous agreement in all cases between raters. Wave-T1-MPRAGE was noninferior in the perception of noise (p < 0.001), motion artifact (p < 0.001), and overall diagnostic quality (p < 0.001).
High-accelerated post-contrast Wave-T1-MPRAGE enabled a two-fold reduction in acquisition time compared to the standard sequence with comparable performance for visualization of enhancing pathology and equivalent perception of noise, motion artifacts and overall diagnostic quality without loss of clinically important information.
• Post-contrast wave-controlled aliasing in parallel imaging (CAIPI) T1-MPRAGE accelerated the acquisition of three-dimensional (3D) high-resolution post-contrast images by more than two-fold. • Post-contrast Wave-T1-MPRAGE was noninferior to standard T1-MPRAGE with unanimous agreement between reviewers (100% in 80 cases) for the visualization of intracranial enhancing lesions. • Wave-T1-MPRAGE was equivalent to the standard sequence in the perception of noise in 94% (75 of 80) of cases and was preferred in 16% (13 of 80) of cases for decreased motion artifact.
高分辨率对比后 T1 加权成像(T1WI)是神经疾病评估的基本序列。T1-MPRAGE 序列已广泛应用于脑内增强病变的可视化。然而,该三维(3D)采集时间长且易产生运动伪影,这通常会影响诊断质量。本研究旨在比较高加速波控并行采集成像(CAIPI)对比后 3D T1-MPRAGE 序列(Wave-T1-MPRAGE)与标准 3D T1-MPRAGE 序列在 3T 脑成像中对增强病变的可视化效果。
本研究纳入 80 例行对比增强脑 MRI 的患者。患者均行标准对比后 T1-MPRAGE 序列(使用 GRAPPA 并行成像技术加速因子 [R] = 2,采集时间 [TA] = 5 分 18 秒)和原型对比后 Wave-T1-MPRAGE 序列(R = 4,TA = 2 分 32 秒)扫描。两位神经放射科医生对这两种序列进行了直接比较评估,对增强显示、锐利度、噪声、运动伪影和整体诊断质量进行评分。使用 15%的非劣效性边界来检验对比后 Wave-T1-MPRAGE 是否不劣于标准 T1-MPRAGE。计算了组内和组间的一致性。对 CNR/SNR 进行了定量评估。
Wave-T1-MPRAGE 在所有病例中均与标准 T1-MPRAGE 具有一致的增强病变显示,具有非劣效性。在噪声(p < 0.001)、运动伪影(p < 0.001)和整体诊断质量(p < 0.001)方面,Wave-T1-MPRAGE 具有非劣效性。
与标准序列相比,高加速对比后 Wave-T1-MPRAGE 使 3D 高分辨率对比后图像的采集时间缩短了两倍以上,在增强病变的可视化方面具有相似的性能,且在噪声、运动伪影和整体诊断质量的感知方面具有等效性,而不会丢失具有临床重要意义的信息。
对比后波控并行采集成像(CAIPI)T1-MPRAGE 通过超过两倍的加速实现了三维(3D)高分辨率对比后图像的采集。
在颅内增强病变的显示方面,对比后 Wave-T1-MPRAGE 与标准 T1-MPRAGE 具有一致的非劣效性(80 例中 100%具有一致性)。
在 94%(80 例中的 75 例)的病例中,Wave-T1-MPRAGE 在噪声感知方面与标准序列相当,而在 16%(80 例中的 13 例)的病例中,Wave-T1-MPRAGE 更受青睐,因为它的运动伪影更小。
