Park Ik Jae, An Hyo Kyung, Chang Yuna, Kim Jin Young
Department of Materials Physics, Sookmyung Women's University, Seoul, 04310, Republic of Korea.
Institute of Advanced Materials and Systems, Sookmyung Women's University, Seoul, 04310, Republic of Korea.
Nano Converg. 2023 May 20;10(1):22. doi: 10.1186/s40580-023-00374-6.
With photovoltaic performance of metal halide perovskite-based solar cells skyrocketing to approximately 26% and approaching the theoretical Shockley-Queisser limit of single junction solar cells, researchers are now exploring multi-junction tandem solar cells that use perovskite materials to achieve high efficiency next-generation photovoltaics. Various types of bottom subcells, including silicon solar cells used commercially in industry, chalcogenide thin film cells, and perovskite cells, have been combined with perovskite top subcells on the strength of facile fabrication methods based on solution processes. However, owing to the nature that photovoltages of the subcells are added up and the structure containing numerous layers, interfacial issues that cause open-circuit voltage (V) deficit need to be handled carefully. In addition, morphological issues or process compatibility make it difficult to fabricate solution-processed perovskite top cells. In this paper, we summarize and review the fundamentals and strategies to overcome interfacial issues in tandem solar cells for high efficiency and stability confronting this field.
随着基于金属卤化物钙钛矿的太阳能电池的光伏性能飙升至约26%,并接近单结太阳能电池的理论肖克利-奎塞尔极限,研究人员目前正在探索使用钙钛矿材料的多结串联太阳能电池,以实现高效的下一代光伏技术。包括工业上商业使用的硅太阳能电池、硫族化物薄膜电池和钙钛矿电池在内的各种类型的底部子电池,已基于溶液工艺的简便制造方法与钙钛矿顶部子电池相结合。然而,由于子电池的光电压会相加以及结构包含众多层的性质,导致开路电压(V)损失的界面问题需要谨慎处理。此外,形态问题或工艺兼容性使得难以制造溶液处理的钙钛矿顶部电池。在本文中,我们总结并回顾了克服串联太阳能电池界面问题以实现该领域高效和稳定性的基本原理及策略。
