微尺度软离子电源调节神经元网络活动。

A microscale soft ionic power source modulates neuronal network activity.

机构信息

Department of Chemistry, University of Oxford, Oxford, UK.

Ludwig Institute for Cancer Research, Nuffield Department of Medicine, University of Oxford, Oxford, UK.

出版信息

Nature. 2023 Aug;620(7976):1001-1006. doi: 10.1038/s41586-023-06295-y. Epub 2023 Aug 30.

Abstract

Bio-integrated devices need power sources to operate. Despite widely used technologies that can provide power to large-scale targets, such as wired energy supplies from batteries or wireless energy transduction, a need to efficiently stimulate cells and tissues on the microscale is still pressing. The ideal miniaturized power source should be biocompatible, mechanically flexible and able to generate an ionic current for biological stimulation, instead of using electron flow as in conventional electronic devices. One approach is to use soft power sources inspired by the electrical eel; however, power sources that combine the required capabilities have not yet been produced, because it is challenging to obtain miniaturized units that both conserve contained energy before usage and are easily triggered to produce an energy output. Here we develop a miniaturized soft power source by depositing lipid-supported networks of nanolitre hydrogel droplets that use internal ion gradients to generate energy. Compared to the original eel-inspired design, our approach can shrink the volume of a power unit by more than 10-fold and it can store energy for longer than 24 h, enabling operation on-demand with a 680-fold greater power density of about 1,300 W m. Our droplet device can serve as a biocompatible and biological ionic current source to modulate neuronal network activity in three-dimensional neural microtissues and in ex vivo mouse brain slices. Ultimately, our soft microscale ionotronic device might be integrated into living organisms.

摘要

生物整合设备需要电源才能运行。尽管有广泛使用的技术可以为大规模目标提供电力,例如电池提供的有线能源或无线能量转换,但仍然迫切需要有效地刺激微观层面的细胞和组织。理想的微型电源应该是生物兼容的、机械灵活的,并且能够产生用于生物刺激的离子电流,而不是像传统电子设备那样使用电子流。一种方法是使用受电鳗启发的软电源;然而,尚未生产出结合所需功能的电源,因为很难获得既可以在使用前保存包含的能量,又可以轻松触发以产生能量输出的微型化单元。在这里,我们通过沉积纳米升水凝胶液滴的脂质支持网络来开发一种微型软电源,该网络利用内部离子梯度来产生能量。与最初受电鳗启发的设计相比,我们的方法可以将一个电源单元的体积缩小 10 倍以上,并且可以储存能量超过 24 小时,从而能够按需运行,功率密度约为 1300 W m,增加了 680 倍。我们的液滴装置可以作为生物兼容和生物离子电流源,调节三维神经微组织和离体小鼠脑片中的神经元网络活动。最终,我们的软微尺度离子电子器件可能会集成到生物体中。
