用于3D打印具有卓越性能的电容式传感器的高导电性和可拉伸纳米结构离子凝胶。

Highly conductive and stretchable nanostructured ionogels for 3D printing capacitive sensors with superior performance.

作者信息

He Xiangnan, Zhang Biao, Liu Qingjiang, Chen Hao, Cheng Jianxiang, Jian Bingcong, Yin Hanlin, Li Honggeng, Duan Ke, Zhang Jianwei, Ge Qi

机构信息

Shenzhen Key Laboratory of Soft Mechanics & Smart Manufacturing, Southern University of Science and Technology, Shenzhen, China.

Department of Mechanical and Energy Engineering, Southern University of Science and Technology, 518055, Shenzhen, China.

出版信息

Nat Commun. 2024 Jul 31;15(1):6431. doi: 10.1038/s41467-024-50797-w.


DOI:10.1038/s41467-024-50797-w
PMID:39085229
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC11291765/
Abstract

Ionogels are promising material candidates for ionotronics due to their excellent ionic conductivity, stretchability, and thermal stability. However, it is challenging to develop 3D printable ionogels with both excellent electrical and mechanical properties. Here, we report a highly conductive and stretchable nanostructured (CSN) ionogel for 3D printing ionotronic sensors. We propose the photopolymerization-induced microphase separation strategy to prepare the CSN ionogels comprising continuous conducting nanochannels intertwined with cross-linked polymeric framework. The resultant CSN ionogels simultaneously achieves high ionic conductivity (over 3 S m), high stretchability (over 1500%), low degree of hysteresis (0.4% at 50% strain), wide-temperature-range thermostability (-72 to 250 °C). Moreover, its high compatible with DLP 3D printing enables the fabrication of complex ionogel micro-architectures with high resolution (up to 5 μm), which allows us to manufacture capacitive sensors with superior sensing performances. The proposed CSN ionogel paves an efficient way to manufacture the next-generation capacitive sensors with enhanced performance.

摘要

由于具有优异的离子导电性、拉伸性和热稳定性,离子凝胶是离子电子学领域很有前景的材料候选者。然而,开发兼具优异电学和力学性能的3D可打印离子凝胶具有挑战性。在此,我们报道了一种用于3D打印离子电子传感器的高导电性和可拉伸的纳米结构(CSN)离子凝胶。我们提出了光聚合诱导微相分离策略来制备CSN离子凝胶,该凝胶由与交联聚合物骨架交织的连续导电纳米通道组成。所得的CSN离子凝胶同时实现了高离子电导率(超过3 S m)、高拉伸性(超过1500%)、低滞后度(在50%应变下为0.4%)、宽温度范围的热稳定性(-72至250°C)。此外,它与数字光处理(DLP)3D打印的高度兼容性使得能够制造具有高分辨率(高达5μm)的复杂离子凝胶微结构,这使我们能够制造具有卓越传感性能的电容式传感器。所提出的CSN离子凝胶为制造性能增强的下一代电容式传感器铺平了一条有效途径。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e514/11291765/8cfae99655bc/41467_2024_50797_Fig6_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e514/11291765/a1478cdc4270/41467_2024_50797_Fig1_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e514/11291765/029729715a41/41467_2024_50797_Fig2_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e514/11291765/0874ec10f14d/41467_2024_50797_Fig3_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e514/11291765/37e6eb270e9b/41467_2024_50797_Fig4_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e514/11291765/b44f3ae9c8f5/41467_2024_50797_Fig5_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e514/11291765/8cfae99655bc/41467_2024_50797_Fig6_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e514/11291765/a1478cdc4270/41467_2024_50797_Fig1_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e514/11291765/029729715a41/41467_2024_50797_Fig2_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e514/11291765/0874ec10f14d/41467_2024_50797_Fig3_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e514/11291765/37e6eb270e9b/41467_2024_50797_Fig4_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e514/11291765/b44f3ae9c8f5/41467_2024_50797_Fig5_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e514/11291765/8cfae99655bc/41467_2024_50797_Fig6_HTML.jpg
