用于聚焦控制的微机电系统可变焦距光学元件

MEMS Varifocal Optical Elements for Focus Control.

作者信息

Liu Chen, Wang Tong, Wang Xin, Chang Manpeng, Jian Yu, Wang Weimin

机构信息

Key Laboratory of Optoelectronic Technology and Systems, Ministry of Education, Chongqing University, Chongqing 400044, China.

Defense Key Disciplines Laboratory of Novel Micro-Nano Devices and System Technology, Chongqing University, Chongqing 400044, China.

出版信息

Micromachines (Basel). 2025 Apr 19;16(4):482. doi: 10.3390/mi16040482.

Abstract

As microelectronic devices become more prevalent daily, miniaturization is emerging as a key trend, particularly in optical systems. Optical systems with volume scanning and imaging capabilities heavily rely on focus control. The traditional focus tuning method restricts the miniaturization of optical systems due to its complex structure and large volume. The recent rapid development of MEMS varifocal optical elements has provided sufficient opportunities for miniaturized optical systems. Here, we review the literature on MEMS varifocal optical elements over the past two decades. Based on light control mechanisms, MEMS varifocal optical elements are divided into three categories: reflective varifocal mirrors, varifocal microlenses, and phased varifocal mirrors. A novel indicator is introduced to evaluate and compare the performance of MEMS varifocal optical elements. A wide range of applications is also discussed. This review can serve as a reference for relevant researchers and engineers.

摘要

随着微电子设备日益普及,小型化正成为一个关键趋势,尤其是在光学系统中。具有体积扫描和成像能力的光学系统严重依赖聚焦控制。传统的聚焦调谐方法由于其结构复杂、体积大,限制了光学系统的小型化。近年来,微机电系统(MEMS)变焦距光学元件的迅速发展为小型化光学系统提供了充足的机会。在此,我们回顾了过去二十年中关于MEMS变焦距光学元件的文献。基于光控机制,MEMS变焦距光学元件分为三类:反射式变焦距镜、变焦距微透镜和相控变焦距镜。引入了一种新颖的指标来评估和比较MEMS变焦距光学元件的性能。还讨论了广泛的应用。这篇综述可为相关研究人员和工程师提供参考。
