Jeong Gyu-Seob, Bae Woorham, Jeong Deog-Kyoon
Department of Electrical and Computer Engineering and Inter-University Semiconductor Research Center, Seoul National University, Seoul 08826, Korea.
Department of Electrical Engineering and Computer Sciences, University of California at Berkeley, Berkeley, CA 94720, USA.
Sensors (Basel). 2017 Aug 25;17(9):1962. doi: 10.3390/s17091962.
The bandwidth requirement of wireline communications has increased exponentially because of the ever-increasing demand for data centers and high-performance computing systems. However, it becomes difficult to satisfy the requirement with legacy electrical links which suffer from frequency-dependent losses due to skin effects, dielectric losses, channel reflections, and crosstalk, resulting in a severe bandwidth limitation. In order to overcome this challenge, it is necessary to introduce optical communication technology, which has been mainly used for long-reach communications, such as long-haul networks and metropolitan area networks, to the medium- and short-reach communication systems. However, there still remain important issues to be resolved to facilitate the adoption of the optical technologies. The most critical challenges are the energy efficiency and the cost competitiveness as compared to the legacy copper-based electrical communications. One possible solution is silicon photonics which has long been investigated by a number of research groups. Despite inherent incompatibility of silicon with the photonic world, silicon photonics is promising and is the only solution that can leverage the mature complementary metal-oxide-semiconductor (CMOS) technologies. Silicon photonics can be utilized in not only wireline communications but also countless sensor applications. This paper introduces a brief review of silicon photonics first and subsequently describes the history, overview, and categorization of the CMOS IC technology for high-speed photo-detection without enumerating the complex circuital expressions and terminologies.
由于对数据中心和高性能计算系统的需求不断增长,有线通信的带宽需求呈指数级增长。然而,传统的电气链路由于趋肤效应、介电损耗、信道反射和串扰而存在频率相关损耗,因此难以满足这一需求,导致严重的带宽限制。为了克服这一挑战,有必要将主要用于长距离通信(如长途网络和城域网)的光通信技术引入到中短距离通信系统中。然而,要促进光技术的应用,仍有一些重要问题需要解决。与传统的基于铜的电气通信相比,最关键的挑战是能源效率和成本竞争力。一种可能的解决方案是硅光子学,许多研究小组对此进行了长期研究。尽管硅与光子世界存在内在的不相容性,但硅光子学很有前景,并且是唯一能够利用成熟的互补金属氧化物半导体(CMOS)技术的解决方案。硅光子学不仅可以用于有线通信,还可以用于无数的传感器应用。本文首先简要介绍硅光子学,随后描述用于高速光电探测的CMOS集成电路技术的历史、概述和分类,而不列举复杂的电路表达式和术语。
