CDM Center, Takara Bio Inc. Nojihigashi 7-4-38, Kusatsu, Shiga, 525-0058, Japan.
Sci Rep. 2019 Mar 18;9(1):4811. doi: 10.1038/s41598-019-41121-4.
Target-specific genome editing using engineered nucleases has become widespread in various fields. Long gene knock-in and single-base substitutions can be performed by homologous recombination (HR), but the efficiency is usually very low. To improve the efficiency of knock-in with single-stranded oligo DNA nucleotides (ssODNs), we have investigated optimal design of ssODNs in terms of the blocking mutation, orientation, size, and length of homology arms to explore the optimal parameters of ssODN design using reporter systems for the detection of single-base substitutions. We have also investigated the difference in knock-in efficiency among the delivery forms and methods of Cas9 and sgRNA. The knock-in efficiencies for optimized ssODNs were much higher than those for ssODNs with no blocking mutation. We have also demonstrated that Cas9 protein/sgRNA ribonucleoprotein complexes (Cas9-RNPs) can dramatically reduce the re-cutting of the edited sites.
利用工程化核酸酶进行靶向基因组编辑已经在各个领域得到广泛应用。通过同源重组(HR)可以实现长基因的敲入和单碱基替换,但效率通常非常低。为了提高单链寡核苷酸(ssODN)介导的基因敲入效率,我们研究了 ssODN 在阻断突变、取向、大小和同源臂长度方面的最佳设计,以利用单碱基替换检测报告系统探索 ssODN 设计的最佳参数。我们还研究了 Cas9 和 sgRNA 的不同递送形式和方法对基因敲入效率的影响。优化后的 ssODN 的基因敲入效率明显高于没有阻断突变的 ssODN。我们还证明 Cas9 蛋白/sgRNA 核糖核蛋白复合物(Cas9-RNPs)可以显著减少编辑位点的再切割。
