飞秒脉冲激光作用于范德华界面的光声 2D 驱动器。

Photoacoustic 2D actuator via femtosecond pulsed laser action on van der Waals interfaces.

机构信息

Photonic Integrated Circuits Center, Key Laboratory of Materials for High-Power Laser, Shanghai Institute of Optics and Fine Mechanics, Chinese Academy of Sciences, Shanghai, 201800, China.

Center of Materials Science and Optoelectronics Engineering, University of Chinese Academy of Sciences, Beijing, 100049, China.

出版信息

Nat Commun. 2023 Apr 14;14(1):2135. doi: 10.1038/s41467-023-37763-8.


DOI:10.1038/s41467-023-37763-8
PMID:37059706
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC10104871/
Abstract

Achieving optically controlled nanomachine engineering can satisfy the touch-free and non-invasive demands of optoelectronics, nanotechnology, and biology. Traditional optical manipulations are mainly based on optical and photophoresis forces, and they usually drive particles in gas or liquid environments. However, the development of an optical drive in a non-fluidic environment, such as on a strong van der Waals interface, remains difficult. Herein, we describe an efficient 2D nanosheet actuator directed by an orthogonal femtosecond laser, where 2D VSe and TiSe nanosheets deposited on sapphire substrates can overcome the interface van der Waals forces (tens and hundreds of megapascals of surface density) and move on the horizontal surfaces. We attribute the observed optical actuation to the momentum generated by the laser-induced asymmetric thermal stress and surface acoustic waves inside the nanosheets. 2D semimetals with high absorption coefficient can enrich the family of materials suitable to implement optically controlled nanomachines on flat surfaces.

摘要

实现光控纳米机械工程可以满足光电、纳米技术和生物学领域对非接触式和非侵入式的需求。传统的光学操控主要基于光学和光泳力,它们通常在气体或液体环境中驱动粒子。然而,在非流体环境中(例如在强范德华界面上)开发光学驱动器仍然具有挑战性。在这里,我们描述了一种由正交飞秒激光驱动的高效二维纳米片执行器,其中沉积在蓝宝石衬底上的二维 VSe 和 TiSe 纳米片可以克服界面范德华力(数十到数百兆帕斯卡的表面密度)并在水平表面上移动。我们将观察到的光致动归因于激光诱导的非对称热应力和纳米片中的表面声波产生的动量。具有高吸收系数的二维半导体可以丰富适用于在平面上实现光控纳米机器的材料家族。
