Hybrid Scheme for Modeling Local Field Potentials from Point-Neuron Networks.

作者信息

Hagen Espen, Dahmen David, Stavrinou Maria L, Lindén Henrik, Tetzlaff Tom, van Albada Sacha J, Grün Sonja, Diesmann Markus, Einevoll Gaute T

机构信息

Institute of Neuroscience and Medicine (INM-6) and Institute for Advanced Simulation (IAS-6) and JARA BRAIN Institute I, Jülich Research Centre, 52425 Jülich, Germany.

Department of Mathematical Sciences and Technology, Norwegian University of Life Sciences, 1430 Ås, Norway.

出版信息

Cereb Cortex. 2016 Dec;26(12):4461-4496. doi: 10.1093/cercor/bhw237. Epub 2016 Oct 20.


DOI:10.1093/cercor/bhw237
PMID:27797828
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC6193674/
Abstract

With rapidly advancing multi-electrode recording technology, the local field potential (LFP) has again become a popular measure of neuronal activity in both research and clinical applications. Proper understanding of the LFP requires detailed mathematical modeling incorporating the anatomical and electrophysiological features of neurons near the recording electrode, as well as synaptic inputs from the entire network. Here we propose a hybrid modeling scheme combining efficient point-neuron network models with biophysical principles underlying LFP generation by real neurons. The LFP predictions rely on populations of network-equivalent multicompartment neuron models with layer-specific synaptic connectivity, can be used with an arbitrary number of point-neuron network populations, and allows for a full separation of simulated network dynamics and LFPs. We apply the scheme to a full-scale cortical network model for a ∼1 mm patch of primary visual cortex, predict laminar LFPs for different network states, assess the relative LFP contribution from different laminar populations, and investigate effects of input correlations and neuron density on the LFP. The generic nature of the hybrid scheme and its public implementation in hybridLFPy form the basis for LFP predictions from other and larger point-neuron network models, as well as extensions of the current application with additional biological detail.

摘要
