Graphene is currently at the forefront of cutting-edge science and technology due to exceptional electronic, optical, mechanical, and thermal properties. However, the absence of a sizeable band gap in graphene has been a major obstacle for application. To open and control a band gap in functionalized graphene, several gapping strategies have been developed. In particular, hydrogen plasma treatment has triggered a great scientific interest, because it has been known to be an efficient way to modify the surface of single-layered graphene and to apply for standard wafer-scale fabrication. Here we show a monolayer chemical-vapour-deposited graphene hydrogenated by indirect hydrogen plasma without structural defect and we demonstrate that a band gap can be tuned as wide as 3.9 eV by varying hydrogen coverage. We also show a hydrogenated graphene field-effect transistor, showing that on/off ratio changes over three orders of magnitude at room temperature.
由于其出色的电子、光学、机械和热性能,石墨烯目前处于前沿科学技术的前沿。然而,石墨烯中不存在可观的带隙一直是其应用的主要障碍。为了在功能化石墨烯中打开和控制带隙,已经开发了几种带隙策略。特别是,氢等离子体处理引发了极大的科学兴趣,因为它已被证明是一种有效修饰单层石墨烯表面并应用于标准晶圆级制造的方法。在这里,我们展示了一种通过间接氢等离子体氢化的单层化学气相沉积石墨烯,且没有结构缺陷,我们证明通过改变氢覆盖率可以将带隙调谐至 3.9 eV 之宽。我们还展示了一种氢化石墨烯场效应晶体管,表明在室温下,其导通/截止比变化超过三个数量级。
