基于卷积神经网络的多发性硬化病变分割中单样本域自适应

One-shot domain adaptation in multiple sclerosis lesion segmentation using convolutional neural networks.

机构信息

Research institute of Computer Vision and Robotics, University of Girona, Spain.

Research institute of Computer Vision and Robotics, University of Girona, Spain; Computer Science Department, Faculty of Computers and Information, Assiut University, Egypt.

出版信息

Neuroimage Clin. 2019;21:101638. doi: 10.1016/j.nicl.2018.101638. Epub 2018 Dec 10.


DOI:10.1016/j.nicl.2018.101638
PMID:30555005
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC6413299/
Abstract

In recent years, several convolutional neural network (CNN) methods have been proposed for the automated white matter lesion segmentation of multiple sclerosis (MS) patient images, due to their superior performance compared with those of other state-of-the-art methods. However, the accuracies of CNN methods tend to decrease significantly when evaluated on different image domains compared with those used for training, which demonstrates the lack of adaptability of CNNs to unseen imaging data. In this study, we analyzed the effect of intensity domain adaptation on our recently proposed CNN-based MS lesion segmentation method. Given a source model trained on two public MS datasets, we investigated the transferability of the CNN model when applied to other MRI scanners and protocols, evaluating the minimum number of annotated images needed from the new domain and the minimum number of layers needed to re-train to obtain comparable accuracy. Our analysis comprised MS patient data from both a clinical center and the public ISBI2015 challenge database, which permitted us to compare the domain adaptation capability of our model to that of other state-of-the-art methods. In both datasets, our results showed the effectiveness of the proposed model in adapting previously acquired knowledge to new image domains, even when a reduced number of training samples was available in the target dataset. For the ISBI2015 challenge, our one-shot domain adaptation model trained using only a single case showed a performance similar to that of other CNN methods that were fully trained using the entire available training set, yielding a comparable human expert rater performance. We believe that our experiments will encourage the MS community to incorporate its use in different clinical settings with reduced amounts of annotated data. This approach could be meaningful not only in terms of the accuracy in delineating MS lesions but also in the related reductions in time and economic costs derived from manual lesion labeling.

摘要

近年来,由于卷积神经网络 (CNN) 方法在表现上优于其他最先进的方法,因此已经提出了几种用于对多发性硬化症 (MS) 患者图像进行自动白质病变分割的 CNN 方法。然而,与用于训练的图像相比,当在不同的图像域中评估 CNN 方法时,其准确性往往会显著下降,这表明 CNN 缺乏对未见影像数据的适应性。在这项研究中,我们分析了强度域自适应对我们最近提出的基于 CNN 的 MS 病变分割方法的影响。对于在两个公共 MS 数据集上训练的源模型,我们研究了 CNN 模型在应用于其他 MRI 扫描仪和协议时的可转移性,评估了从新域中需要的最少注释图像数量以及重新训练以获得可比准确性所需的最少层数。我们的分析包括来自临床中心和公共 ISBI2015 挑战赛数据库的 MS 患者数据,这使我们能够将我们的模型的域自适应能力与其他最先进的方法进行比较。在两个数据集上,我们的结果表明,即使在目标数据集可用的训练样本数量较少的情况下,我们提出的模型也能够有效地将先前获取的知识应用于新的图像域。对于 ISBI2015 挑战赛,我们仅使用单个病例训练的一次性域自适应模型的性能与其他使用整个可用训练集进行完全训练的 CNN 方法相似,从而获得与人类专家评分者相似的性能。我们相信,我们的实验将鼓励 MS 社区在不同的临床环境中使用它,并且需要的注释数据量减少。这种方法不仅在描绘 MS 病变的准确性方面有意义,而且在手动病变标记所带来的时间和经济成本的相关减少方面也有意义。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/46eb/6413299/2f1e43ecf075/gr4.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/46eb/6413299/8b056905f380/gr1.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/46eb/6413299/c44b3b7ab399/gr2.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/46eb/6413299/8288b02d424a/gr3.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/46eb/6413299/2f1e43ecf075/gr4.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/46eb/6413299/8b056905f380/gr1.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/46eb/6413299/c44b3b7ab399/gr2.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/46eb/6413299/8288b02d424a/gr3.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/46eb/6413299/2f1e43ecf075/gr4.jpg
