类器官追踪器:使用机器学习和手动纠错进行高效的细胞追踪。

OrganoidTracker: Efficient cell tracking using machine learning and manual error correction.

机构信息

AMOLF, Amsterdam, The Netherlands.

Okinawa Institute of Science and Technology Graduate University (OIST), Onna-son, Okinawa, Japan.

出版信息

PLoS One. 2020 Oct 22;15(10):e0240802. doi: 10.1371/journal.pone.0240802. eCollection 2020.

DOI:10.1371/journal.pone.0240802
PMID:33091031
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC7580893/
Abstract

Time-lapse microscopy is routinely used to follow cells within organoids, allowing direct study of division and differentiation patterns. There is an increasing interest in cell tracking in organoids, which makes it possible to study their growth and homeostasis at the single-cell level. As tracking these cells by hand is prohibitively time consuming, automation using a computer program is required. Unfortunately, organoids have a high cell density and fast cell movement, which makes automated cell tracking difficult. In this work, a semi-automated cell tracker has been developed. To detect the nuclei, we use a machine learning approach based on a convolutional neural network. To form cell trajectories, we link detections at different time points together using a min-cost flow solver. The tracker raises warnings for situations with likely errors. Rapid changes in nucleus volume and position are reported for manual review, as well as cases where nuclei divide, appear and disappear. When the warning system is adjusted such that virtually error-free lineage trees can be obtained, still less than 2% of all detected nuclei positions are marked for manual analysis. This provides an enormous speed boost over manual cell tracking, while still providing tracking data of the same quality as manual tracking.

摘要

延时显微镜通常用于观察类器官中的细胞,从而可以直接研究细胞分裂和分化模式。人们对类器官中的细胞追踪越来越感兴趣,这使得能够在单细胞水平上研究它们的生长和动态平衡。由于手动追踪这些细胞非常耗时,因此需要使用计算机程序进行自动化。不幸的是,类器官的细胞密度高,细胞运动速度快,这使得自动细胞追踪变得困难。在这项工作中,开发了一种半自动细胞追踪器。为了检测细胞核,我们使用了一种基于卷积神经网络的机器学习方法。为了形成细胞轨迹,我们使用最小成本流求解器将不同时间点的检测结果连接起来。该追踪器会对可能存在错误的情况发出警告。对于体积和位置快速变化的细胞核,以及核分裂、出现和消失的情况,会进行手动复查。当调整警告系统以获得几乎无错误的谱系树时,仍有不到 2%的所有检测到的细胞核位置需要进行手动分析。与手动细胞追踪相比,这大大提高了速度,同时仍然提供了与手动追踪相同质量的追踪数据。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f4c/7580893/60e854e7c0da/pone.0240802.g005.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f4c/7580893/fed84074d620/pone.0240802.g001.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f4c/7580893/edc61c5b0a3d/pone.0240802.g002.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f4c/7580893/cf543564cc5b/pone.0240802.g003.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f4c/7580893/4caa0aa6a8df/pone.0240802.g004.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f4c/7580893/60e854e7c0da/pone.0240802.g005.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f4c/7580893/fed84074d620/pone.0240802.g001.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f4c/7580893/edc61c5b0a3d/pone.0240802.g002.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f4c/7580893/cf543564cc5b/pone.0240802.g003.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f4c/7580893/4caa0aa6a8df/pone.0240802.g004.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f4c/7580893/60e854e7c0da/pone.0240802.g005.jpg
