Development of Phantoms for Multimodal Magnetic Resonance Imaging and Magnetic Particle Imaging.

作者信息

Arenas Maria Alejandra Ardila, Gutkelch Dirk, Kosch Olaf, Brühl Rüdiger, Wiekhorst Frank, Löwa Norbert

机构信息

Working Group 8.23 Metrology for Magnetic Nanoparticles, Physikalisch-Technische Bundesanstalt, 10587 Berlin, Germany.

Departamento de Ciencias Aplicadas, Institución Universitaria ITM, Medellin 050034, Colombia.

出版信息

Polymers (Basel). 2022 Sep 20;14(19):3925. doi: 10.3390/polym14193925.


DOI:10.3390/polym14193925
PMID:36235873
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC9571530/
Abstract

Phantoms are crucial for the development of imaging techniques based on magnetic nanoparticles (MNP). They serve as test objects to simulate application scenarios but are also used for quality assurance and interlaboratory comparisons. Magnetic particle imaging (MPI) is excellent for specifically detecting magnetic nanoparticles (MNP) without any background signals. To obtain information about the surrounding soft tissue, MPI is often used in combination with magnetic resonance imaging (MRI). For such application scenarios, this poses a challenge for phantom fabrication, as they need to accommodate MNP as well as provide MR visibility. Recently, layer-by-layer fabrication of parts using Additive Manufacturing (AM) has emerged as a powerful tool for creating complex and patient-specific phantoms, but these are characterized by poor MR visibility of the AM material. We present the systematic screening of AM materials as candidates for multimodal MRI/MPI imaging. Of all investigated materials, silicone (Dreve, Biotec) exhibited the best properties with sufficient MR-signal performance and the lowest absorption of MNP at the interface of AM materials. With the help of AM and the selection of appropriate materials, we have been able to produce suitable MRI/MPI phantoms.

摘要
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/8b9c/9571530/a785e48d3ee1/polymers-14-03925-g005.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/8b9c/9571530/e4a91213a380/polymers-14-03925-g001.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/8b9c/9571530/46e6f36349c0/polymers-14-03925-g002.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/8b9c/9571530/58904eedc21c/polymers-14-03925-g003.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/8b9c/9571530/fad0bb785e7e/polymers-14-03925-g004.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/8b9c/9571530/a785e48d3ee1/polymers-14-03925-g005.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/8b9c/9571530/e4a91213a380/polymers-14-03925-g001.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/8b9c/9571530/46e6f36349c0/polymers-14-03925-g002.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/8b9c/9571530/58904eedc21c/polymers-14-03925-g003.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/8b9c/9571530/fad0bb785e7e/polymers-14-03925-g004.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/8b9c/9571530/a785e48d3ee1/polymers-14-03925-g005.jpg
